Guangxi Yuchai engine was developed products by the German FEV technology.The machine body and cylinder are made of the high-strength alloy cast iron, reinforced in high degree, fixed one-piece forged steel crankshaft.bearings, small size, light weight and high reliability;normally the overhaul period must be after 12,000 hours. The diesel generator set has a compact structure, large power reserve, high reliability, good regulation speed performance and so on good characteristics. Welcome to choose.
Details introduction:
| Type | Output Power |
Cuurrent (A) | Engine model | Cyl. |
Bore (mm) |
Stroke (mm) |
FuelCon. (L) |
Dis. g/kw.h |
Dimension(mm ) L*W*H |
Weight (kg) | |
| KW | KVA | ||||||||||
| NHY-18GF | 18 | 22.5 | 32.4 | YC2108D | 2 | 108 | 120 | 2.20 | ≤225 | 1700*700*1000 | 650 |
| NHY-24GF | 24 | 30 | 43.2 | YC2115D | 2 | 115 | 120 | 2.49 | ≤220 | 1700*700*1000 | 650 |
| NHY-30GF | 30 | 37.5 | 54 | YC2115ZD | 2 | 108 | 115 | 2.11 | ≤205 | 1700*750*1000 | 900 |
| NHY-40GF | 40 | 50 | 72 | YC4D60-D21 | 4 | 108 | 115 | 4.21 | ≤205 | 1800*750*1200 | 920 |
| NHY-50GF | 50 | 62.5 | 90 | YC4D85Z-D20 | 4 | 108 | 115 | 4.21 | ≤200 | 1800*750*1200 | 950 |
| NHY-60GF | 60 | 75 | 108 | YC4D90Z-D20 | 4 | 108 | 115 | 4.21 | ≤200 | 2000*800*1250 | 1100 |
| NHY-64GF | 64 | 80 | 115.2 | YC4A100Z-D20 | 4 | 108 | 125 | 4.58 | ≤200 | 2250*800*1300 | 1200 |
| NHY-90GF | 90 | 112.5 | 162 | YC6B135Z-D20 | 6 | 108 | 125 | 6.87 | ≤202 | 2250*800*1300 | 1300 |
| NHY-100GF | 100 | 125 | 180 | YC6B155L-D21 | 6 | 108 | 125 | 6.87 | ≤200 | 2300*800*1300 | 1500 |
| NHY-120GF | 120 | 150 | 216 | YC6B180L-D20 | 6 | 108 | 132 | 7.26 | ≤192 | 2300*830*1300 | 1600 |
| NHY-132GF | 132 | 165 | 237.6 | YC6A200L-D20 | 6 | 108 | 132 | 7.26 | ≤195 | 2300*830*1300 | 1700 |
| NHY-150GF | 150 | 187.5 | 270 | YC6A230L-D20 | 6 | 108 | 132 | 7.26 | ≤192 | 2400*970*1500 | 2100 |
| NHY-160GF | 160 | 200 | 288 | YC6G245L-D20 | 6 | 112 | 132 | 7.80 | ≤195 | 2500*970*1500 | 2300 |
| NHY-200GF | 200 | 250 | 360 | YC6M350L-D20 | 6 | 120 | 145 | 9.84 | ≤197 | 3100*1050*1750 | 2750 |
| NHY-250GF | 250 | 312.5 | 450 | YC6MK420L-D20 | 6 | 123 | 145 | 10.34 | ≤195 | 3200*1150*1750 | 3000 |
| NHY-280GF | 280 | 350 | 504 | YC6MK420L-D20 | 6 | 123 | 145 | 10.34 | ≤195 | 3200*1150*1750 | 3000 |
| NHY-300GF | 300 | 375 | 540 | YC6MJ480L-D20 | 6 | 131 | 145 | 11.73 | ≤197 | 3200*1200*1750 | 3100 |
| NHY-320GF | 320 | 400 | 576 | YC6MJ480L-D20 | 6 | 131 | 145 | 11.73 | ≤195 | 3200*1200*1750 | 3100 |
| NHY-360GF | 350 | 437.5 | 630 | YC6T550L-D21 | 6 | 145 | 165 | 16.35 | ≤195 | 3300*1250*1850 | 3500 |
| NHY-400GF | 400 | 500 | 720 | YC6T600L-D22 | 6 | 145 | 165 | 16.35 | ≤195 | 3400*1500*1970 | 3900 |
| NHY-440GF | 440 | 550 | 792 | YC6T660L-D20 | 6 | 145 | 165 | 16.35 | ≤195 | 3500*1500*1970 | 4000 |
| NHY-460GF | 460 | 575 | 828 | YC6T700L-D20 | 6 | 145 | 165 | 16.35 | ≤195 | 3500*1500*1950 | 4000 |
| NHY-500GF | 500 | 625 | 900 | YC6TD780L-D20 | 6 | 145 | 165 | 16.35 | ≤195 | 3600*1600*1950 | 4100 |
| NHY-550GF | 550 | 687.5 | 990 | YC6TD840L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 3650*1600*2000 | 4200 |
| NHY-650GF | 650 | 812.5 | 1170 | YC6C1020L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 4000*1500*2100 | 5500 |
| NHY-700GF | 700 | 875 | 1260 | YC6C1070L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 4200*1650*2100 | 5800 |
| NHY-800GF | 800 | 1000 | 1440 | YC6C1220L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 4300*1750*2200 | 6100 |
| NHY-880GF | 880 | 1100 | 1584 | YC6C1320L-D20 | 6 | 200 | 210 | 39.58 | ≤195 | 5200*2150*2500 | 7500 |
| NHY-1000GF | 1000 | 1250 | 1800 | YC12VC1680L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5000*2000*2500 | 9800 |
| NHY-1100GF | 1100 | 1375 | 1980 | YC12VC1680L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5100*2080*2500 | 9900 |
| NHY-1200GF | 1200 | 1500 | 2160 | YC12VC2070L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5300*2080*2500 | 10000 |
| NHY-1320GF | 1320 | 1650 | 2376 | YC12VC2070L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5500*2180*2550 | 11000 |
| NHY-1500GF | 1500 | 1875 | 2700 | YC12VC2270L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5600*2280*2600 | 12000 |
| NHY-1600GF | 1600 | 2000 | 2880 | YC12VC2510L-D20 | 12 | 200 | 210 | 79.17 | ≤195 | 5600*2280*2600 | 12500 |
1.Above technical parameters speed is 500RPM, frequency 50HZ, rated voltage 400 / 230V, power factor 0.8, and 3-phase 4-wire. 60HZ diesel generators can be made according to the specific needs of customers.
2.Alternator is based on customer needs, you can choose from Wuxi Stamford, Shanghai Hengsheng(recommend), Shanghai marathon and other famous brands.
3.The parameter list above are for reference only, subject to change without notice.
